HANDS-ON LAB: BUILDING ACTIVE DIRECTORY ORGANIZATIONAL STRUCTURE WITH ADUC

Estimated Reading & Lab Time: 20 minutes

Struggling to organize users across departments in Active Directory? This hands-on lab walks you through creating a realistic OU structure with users and groups using ADUC – covering 80% of daily AD admin tasks. You’ll learn What You’ll Learn: Build 3-level OU hierarchy (Departments → Teams → Sub-teams), create 25+ users across 4 departments, security groups, PowerShell automation, and verification commands.

LAB PREREQUISITES

• Windows Server 2022/2019/2016 with Active Directory Domain Services (AD DS) installed and promoted as Domain Controller
• Logged in as Domain Administrator (e.g., CORP\Administrator)
• Active Directory Users and Computers (ADUC) available: Server Manager → Tools → Active Directory Users and Computers
• PowerShell with ActiveDirectory module: Import-Module ActiveDirectory
• Lab Environment: Single-domain setup (e.g., corp.local) – no production changes!

⚠️ Warning: Uncheck “Protect from accidental deletion” on OUs for easy lab cleanup. Re-enable in production. Backup NTDS.dit (C:\Windows\NTDS\ntds.dit) before starting.²

STEP 1: CREATE DEPARTMENTAL OU STRUCTURE

Mirror a real SMB with IT, Finance, HR, Marketing departments and sub-teams.

1. Open ADUC (dsa.msc)
2. Right-click your domain (e.g., corp.local) → New → Organizational Unit
3. Create top-level OUs (uncheck protection for lab):

4. Create sub-OUs (Right-click parent OU → New → OU):

IT → Systems Team
IT → Network Team
Finance → Accountants
HR → Recruiters
Marketing → Sales Team

Expected Result: 4 top-level + 6 sub-OUs. Refresh ADUC to verify structure.

STEP 2: CREATE SECURITY GROUPS

Groups assign permissions (e.g., AWS Console Access, File Share Read).

1. Right-click IT → Systems Team → New → Group
2. Configure groups (Global scope, Security type – most common):

Name: Windows-Admins | Scope: Global | Type: Security
Name: Network-Admins | Scope: Global | Type: Security

3. Repeat in other OUs:

Pro Tip: Global groups for cross-forest access; nest in Domain Local for permissions.

STEP 3: CREATE & POPULATE USERS

Add 25 users simulating 2 locations (NY/Hospital-LA style).

1. Right-click OU → New → User
2. Example: IT → Systems Team:
   • First: John | Last: Smith | Logon: jsmith
   • Password: P@ssw0rd123 | Check: “Password never expires” (lab only)
   • Finish → Right-click user → Properties → Member Of → Add → Windows-Admins
3. Copy-Paste Users (create 5 per department):

IT-Systems: jsmith, mjohnson, rwilson, sgarcia, tlee
IT-Network: dkim, lmartin, pchen, kwalker, hnguyen
Finance: abrown, cwilson, ejones, fgreen, hwhite
HR: imorales, jrodriguez, klopez, mmendez, ngomez
Marketing: ohernandez, pperez, qramirez, rsanchez, ttorres

PowerShell Bulk Create (Run as Admin):

Import-Module ActiveDirectory
$Users = @(
    @{Name='John Smith';Sam='jsmith';OU='OU=Systems Team,OU=IT,DC=corp,DC=local';Group='Windows-Admins'}
    @{Name='Mary Johnson';Sam='mjohnson';OU='OU=Systems Team,OU=IT,DC=corp,DC=local';Group='Windows-Admins'}
    # Add more...
)
foreach ($User in $Users) {
    $Pass = ConvertTo-SecureString "P@ssw0rd123" -AsPlainText -Force
    New-ADUser -Name $User.Name -SamAccountName $User.Sam -Path $User.OU -AccountPassword $Pass -Enabled $true
    Add-ADGroupMember -Identity $User.Group -Members $User.Sam
}
Get-ADUser -Filter * | Export-Csv users.csv  # Verify & Export [web:10][web:26]

Output: 25 enabled users in OUs, added to groups. Verify: Right-click group → Properties → Members.

STEP 4: SIMULATE ORG CHANGES & VERIFY

Test real-world scenarios.

1. Move Users: Drag jsmith from IT-Systems to IT-Network (inheritance preserved).
2. PowerShell Restructure:

# Move 10 users between OUs
Get-ADUser -Filter "Department -eq 'Sales'" | Move-ADObject -TargetPath "OU=Sales Team,OU=Marketing,DC=corp,DC=local"
# Export report
Get-ADUser -Filter * -Properties * | Export-Csv report.csv

3. Verify:

dsquery user OU=IT,DC=corp,DC=local  # List IT users
Get-ADGroupMember "Windows-Admins"    # Group members [web:5]

✅ Success Check: 25 users, 8 groups, hierarchical OUs. Run dsquery ou DC=corp,DC=local – no errors.

KEY TAKEAWAYS

• OU Hierarchy: Department → Team → Sub-team enables GPO/delegation
• Groups ≠ OUs: Groups for permissions; OUs for policy/organization
• PowerShell Scales: Bulk ops save hours in production
• Lab → Prod: Enable OU protection, enforce password changes

FAQ

Q: Users in wrong OU after move? A: GPO inheritance follows new OU. Re-apply policies via gpupdate /force.

Q: “Access Denied” creating OUs? A: Use Domain Admin or delegate: Right-click OU → Delegate Control.

Q: Bulk delete for cleanup? A: Remove-ADOrganizationalUnit -Recursive -Confirm:$false "OU=IT,DC=corp,DC=local".

NEXT STEPS

Practice daily: Day 1 recreate from memory; Day 3 mimic your company chart. Extend this lab with GPOs or join clients to domain.
